Autonics TMH4-N2CB Advanced PID Temperature Controller (48×48 mm, Multi-Output)
The Autonics TMH4-N2CB is a high-performance 48×48 mm PID temperature controller with advanced control and alarm functions.
It supports thermocouple/RTD inputs with relay control output, alarm output, and communication capability for industrial automation.
The Autonics TMH4-N2CB is a high-performance PID temperature controller designed for complex industrial temperature control applications. With its 48 × 48 mm DIN size, it fits standard control panels while offering advanced control algorithms, multiple outputs, and alarm functions.
The TMH series is ideal for OEM machinery, process plants, and automation panels where precision, reliability, and expandability are required.
Compact 48 × 48 mm DIN panel size
High-accuracy PID temperature control
Supports thermocouple and RTD sensor inputs
Relay control output for heating control
Alarm output for temperature monitoring
Fast sampling rate for stable control
Auto-tuning and self-diagnostic functions
Designed for continuous industrial operation
| Parameter | Specification |
|---|---|
| Product Type | Advanced PID Temperature Controller |
| Model | TMH4-N2CB |
| Series | TMH |
| Panel Size | 48 × 48 mm |
| Sensor Input | Thermocouple / RTD |
| Control Method | ON/OFF, P, PI, PD, PID |
| Control Output | Relay |
| Alarm Output | 2 Alarm outputs |
| Sampling Rate | High-speed (model dependent) |
| Display Accuracy | ±0.3% of FS |
| Power Supply | 100–240 VAC |
| Operating Temperature | −10 to +50 °C |
| Mounting | Panel Mount |
Industrial heaters and furnaces
Plastic and rubber processing machines
Chemical and pharmaceutical equipment
Packaging and sealing machines
OEM automation panels
Advanced process temperature control
Autonics TMH4-N2CB Temperature Controller
Panel mounting brackets
Instruction manual
Q1. What does “N2CB” indicate in the model number?
“N2” indicates dual alarm outputs, and “C” indicates relay control output.
Q2. Which sensors are supported?
Supports thermocouples (K, J, T, E, etc.) and Pt100 RTD sensors.
Q3. Does this controller support PID control?
Yes. It supports ON/OFF, P, PI, PD, and PID control with auto-tuning.
Q4. Is this suitable for high-precision applications?
Yes. TMH series controllers are designed for high-accuracy industrial processes.
Q5. What is the panel cut-out size?
Fits 48 × 48 mm DIN panel cut-outs.
